CANNONDALE MAVARO NEO 5 LOW STEPTHRU BIKE

An e-bike that elevates the art of commuting. Functionality meets pleasure. Comfort meets practicality. Speed meets style. The best way to move, whether you're going from point A to point B, or just riding with no destination in mind.

This comfortable and versatile e-bike is designed for fast, easy, and fun city riding. Equipped with our lightweight and durable SmartForm C2 aluminum frame. The aluminum frame features a practical low step-thru design. The power is provided by the reliable Bosch ActiveLine motor and a 500Wh battery that offer ample range with reduced weight, while the Shimano CUES 9-speed ensures smooth shifting for any terrain. Everything you need for errands, commuting, or simply enjoying your ride.

The new Bosch Smart System Active Line motor and 500Wh battery provide effortless power.

This drive system offers pedal assist up to a maximum speed of 25 km/h. Beyond that, it's all you.

Up to 110 km of assisted range means you can go anywhere and back.

The Mavaro Neo 5 is powered by the new Bosch Active Line motor with a 500Wh battery, which increases power up to 110%, and is equipped with a Bosch LED remote display on the handlebar. Effortless acceleration, convincing versatility, and up to 110 km range on a single charge.

With its 63 mm travel fork, aluminum fenders, high-capacity rear rack (Racktime compatible), front and rear lights, comfortable handlebars, and agile gearing, the new Mavaro Neo 5 is your perfect partner for daily commuting.

Every detail on the Mavaro Neo has been designed to maximize riding fun. The comfortable riding position and stability. Integrated lights to see and be seen. All contributing to a wonderfully serene riding experience.

CANNONDALE MAVARO NEO 5 LOW STEPTHRU BIKE MAIN FEATURES:

• The SmartForm C2 aluminum frame is lightweight yet durable, with an integrated headtube reflector.
• Smooth and quiet Bosch Active Line Drive motor with up to 40Nm torque and a maximum support of 250%.
• Bosch PowerTube 500Wh battery for an excellent balance of range and weight.
• Shimano CUES 9-speed drivetrain offers smooth and reliable shifting.
• Suntour Mobie fork smoothens the ride with 63 mm of travel.

THE BIKE IS DELIVERED PRE-ASSEMBLED BY US*

TECHNICAL SPECIFICATIONS

FRAMESET

• Frame: SmartForm C2 Alloy, low step-thru, removable 625Wh downtube battery, integrated headtube reflector, tapered headtube, internal cable routing, 135mm QR hub spacing, IS disc mount, motor protection
• Fork: SR Suntour Mobie A32, 63mm travel, coil with preload adjuster, lockout, crown light mount, 44mm offset
• Headset: Semi-Integrated, Tapered; 1-1/8"-1-1/2"

E-SYSTEM

• Motor: Bosch Active Line Smart System, 25 km/h
• Battery: Bosch PowerTube, 500Wh
• Battery Charger: Bosch 2A
• Display: Bosch LED remote

DRIVETRAIN

• Rear Derailleur: Shimano CUES 4020
• Shifters: Shimano CUES 4000, 9-speed
• Chain: KMC E500
• Crankset: FSA for Bosch
• Cassette: Shimano CUES 400, 11-36, 9-speed

BRAKES

• Brakes: Shimano MT400 hydraulic disc, 180/180mm RT30 rotors
• Brake Levers: Shimano MT400 hydraulic disc

WHEELS

• Rims: Alloy, double wall, 32 hole, 25mm internal width, disc-specific
• Spokes: Stainless Steel, 14g
• Tire Size: 2.2
• Wheel Size: 27.5"/29"
• Hubs: (F) Shimano MT400B, 110x15mm thru-axle / (R) Shimano UR600, 135QR
• Tires: Continental eContact Plus w/ reflective sidewalls 27.5x2.20" 55-584 (SM), 29x2.20" 55-622 (MD-XL)

COMPONENTS

• Handlebar: Cannondale E-Series Alloy, ergo backsweep, 680mm
• Stem: Cannondale 3, Alloy, 31.8mm clamp
• Grips: Cannondale Ergo Fitness Dual Density, Lock-on
• Saddle: Selle Royal Vivo Active
• Seatpost: Cannondale 3, 6061 Alloy, 31.6

*PRO-M STORE OFFERS FREE PRE-ASSEMBLY SERVICE: SEATPOST, FORK, DERAILLEUR, AND BRAKES ARE ALREADY ASSEMBLED
