MONDRAKER SUPERFOXY 2025

• Frame

  SuperFoxy 29 6061 Alloy Stealth Evo, hydroformed tubes, Zero Suspension System, 160 mm travel, Forward Geometry, monoblock upper link, SuperBoost 12x157 mm rear axle, tapered head tube, BSA 73 mm bottom bracket, dedicated 1X drivetrain design, internal cable routing for dropper post, sealed bearings with maximum load capacity, ISCG 05

  Sizes

  S: 380 mm / M: 420 mm / L: 470 mm / XL: 510 mm

  Shock Absorber

  Fox DHX Performance, 205x65mm. Settings: 2P compression, low-speed rebound, spring preload. Upper Trunnion mount, 22.2x10 mm lower bushings

  Shock Adjustment

  Compression C40, rebound RL50, LMM, B40. Spring calibration: S size 350 lbs (158.75 kg), M size 400 lbs (181.43 kg), L size 450 lbs (204.11 kg), XL size 500 lbs (226.79 kg)

  Fork

  Fox 38 29 Float FIT GRIP RHYTHM, 170mm, tapered head tube, Boost 15x110mm axle, 44mm offset. Adjustments: 3-position micro-adjustable compression, rebound adjustment, air preload

  Headset

  ONOFF ZS44/ZS56, 1-1/8" and 1.5" tapered head tube, sealed ACB bearings, upper 42x30x7x45°, lower 52x40x8x45°

  Stem

  ONOFF S3 30 mm 0°, forged 6061 alloy, 31.8 mm bar clamp

  Handlebar

  ONOFF S3 1.0 6061 alloy, rise: 25 mm, width: 800 mm, backsweep 8°, upsweep 5°, 31.8 mm clamp. L and XL sizes: rise 1.5.

  Grips

  ONOFF Beehive, 1-lock-on, 135 mm

  Seatpost

  ONOFF Pija internal telescopic, 31.6 mm diameter, 1X remote lever with bearing, S size: 140-115 mm (388-235 mm), M size: 160-135 mm (428-255 mm), L size: 180-155 mm (468-275 mm), XL size: 210-185 mm (528-305 mm)

  Saddle

  SDG BEL-AIR 3.0, LPU foam, steel rails

  Front Brake

  Sram DB8, 4-piston caliper, 200 mm monobloc Centerline rotor with 6-bolt IS mount, organic pads with steel backing

  Rear Brake

  Sram DB8, 4-piston caliper, 200 mm monobloc Centerline rotor with 6-bolt IS mount, organic pads with steel backing

  Brake Levers

  Sram DB8, tool-free reach adjustment, lever pivot bearings

  Wheels

  e*thirteen Grappler Core, IW30 Hookless, welded 6066 aluminum, internal width 30 mm, tubeless ready, 28 spokes

  Spokes

  e*thirteen custom triple thickness black alloy spokes, alloy nipples, nipple washers

  Front Hub Axle

  e*thirteen Boost 15x110 mm, triple seal, anodized finish, 6-bolt IS mount

  Rear Hub Axle

  e*thirteen Superboost 12x157 mm, triple seal, anodized finish, 6-bolt IS mount

  Front Tire

  Maxxis Assegai 29x2.50 WT, EXO+, TR, tubeless ready, 3C compound, Super Tacky tread pattern

  Rear Tire

  Maxxis DHR II 29x2.40 WT, EXO+, TR, tubeless ready, 3C compound, Super Tacky tread pattern
