Frame

SuperFoxy 29 6061 Alloy Stealth Evo, hydroformed tubes, Zero Suspension System, 160 mm travel, Forward Geometry, one-piece upper link, SuperBoost 12x157 mm rear axle, tapered head tube, 73 mm BSA bottom bracket, dedicated 1X drivetrain design, internal cable routing for dropper seatpost, sealed high-load capacity bearings, ISCG 05.

Sizes

S: 380mm / M: 420mm / L: 470mm / XL: 510mm

Shock

Öhlins TTX 22M Coil 205X65mm. Settings: high-speed compression lever with climb mode, low-speed compression, rebound, air preload. Trunnion mount upper, 22.2x10 mm lower bushings.

Shock Adjustment

Compression C10, rebound R20. Spring rate: size S 343 lbs (155.58 kg), size M 411 lbs (186.42 kg), size L 457 lbs (207.29), size XL 502 lbs (227.7 kg).

Fork

Öhlins RXF 38 M.2 29, 170 mm, TTX18 Twin Tube cartridge, tapered steerer, Boost 15x110 mm axle, 44 mm offset. Settings: high-speed compression lever with climb mode, low-speed compression, rebound, air preload, air chamber ramp.

Components
